AFM探針

高分辨率 AFM用于具有挑戰(zhàn)性的前沿研究

清空
Spring Constant
Resonance Frequency
Cantilever Length
Cantilever Geometry
Cantilever Coating
Cantilever Material
Tip Radius(Nom)
Tip Geometry
Tip Coating
Tip Height
Number Of Cantilevers
Sample
Afm
Work Mode
Application
每頁顯示 條記錄
Frequency
Nom: 300KHz
Spring Const.
Nom: 40N/m
Geometry
Rectangular
Tip Radius
50nm
Material
0.01 - 0.025 Ωcm Antimony (n) doped Si
Coating
B: Reflective Aluminum
Frequency
Nom: 13KHz
Spring Const.
Nom: 0.2N/m
Geometry
Rectangular
Tip Radius
8nm
Material
0.01 - 0.025 Ωcm Antimony (n) doped Si
Coating
Frequency
Nom: 13KHz
Spring Const.
Nom: 0.2N/m
Geometry
Rectangular
Tip Radius
8nm
Material
0.01 - 0.025 Ωcm Antimony (n) doped Si
Coating
B: Reflective Aluminum
Frequency
Nom: 13KHz
Spring Const.
Nom: 0.2N/m
Geometry
Rectangular
Tip Radius
8nm
Material
0.01 - 0.025 Ωcm Antimony (n) doped Si
Coating
B: Reflective Aluminum
Frequency
Nom: 13KHz
Spring Const.
Nom: 0.2N/m
Geometry
Rectangular
Tip Radius
8nm
Material
0.01 - 0.025 Ωcm Antimony (n) doped Si
Coating
Frequency
Nom: 1400KHz
Spring Const.
Nom: 18N/m
Geometry
Triangular
Tip Radius
5nm
Material
Silicon Nitride
Coating
B: Reflective Aluminum
Frequency
Nom: 450KHz
Spring Const.
Nom: 1.8N/m
Geometry
Triangular
Tip Radius
5nm
Material
Silicon Nitride
Coating
B: Reflective Gold
Frequency
Nom: 300KHz
Spring Const.
Nom: 0.8N/m
Geometry
Triangular
Tip Radius
5nm
Material
Silicon Nitride
Coating
B: Reflective Gold
Frequency
Nom: 110KHz
Spring Const.
Nom: 0.25N/m
Geometry
Special
Tip Radius
5nm
Material
Silicon Nitride
Coating
B: Proprietary reflective coating
